| Product model(µm) | ST200E | ST300E | ST400E | ST600F |
|---|---|---|---|---|
| Core diameter(µm) | 200 | 300 | 400 | 600 |
| Cladding diameter(µm) | 500 | 500 | 500 | 750 |
| Coating diameter | 780 | 780 | 780 | 1100 |
| Core material | Pure quartz (Low-OH) | |||
| Cladding material | Doped quartz material | |||
| Numerical aperture(NA) | 0.22 | |||
| Two cladding numerical(NA) | NA 0.37 OR NA 0.46 | |||
| Operating wavelength(nm) | 400-2400 | |||
| Length(m) | 3, 5, 10 (default length is 5 meters, customizable) | |||
| Specification | Details |
|---|---|
| Fiber Core Diameter (μm) | 200, 300, 400, 600, 800 |
| Fiber Core Material | High purity fused silica (Low-OH) |
| Fiber Type | Step-index fiber as standard; Graded-index fiber on request |
| Numerical Aperture (NA) | 0.22 as standard, others on request |
| Operating Wavelength (nm) | 400-2400 |
| Protection Tube Diameter (mm) | 8 |
| Cable Lengths (m) | 3, 5, 10, 20, etc. (customizable) |
